Swarovski ATX/STX/BTX Objective Module Series — Modular Viewfinder Objective Lens Modules
🧭 Product Introduction
The Swarovski ATX/STX/BTX Objective Module series offers four diameter options (65 mm, 85 mm, 95 mm, and 115 mm).
All employ SWAROVISION optical technology and multi-layer coating design.
It can be used with ATX, STX, or BTX eyepiece modules.
Combine freely according to your observation needs to meet all applications, from lightweight and portable to extreme brightness.
Each module is crafted with Austrian precision, featuring a robust structure and waterproof/fog-proof design.
It is an ideal choice for professional observers and nature photography enthusiasts.
⚙️ Key Features
-
Modular design: Can be used with ATX / STX / BTX eyepiece modules.
-
Multiple caliber options:
-
65 mm → Lightweight and portable, suitable for mountain climbing and travel.
-
85 mm → Balance between brightness and weight.
-
95 mm → High resolution and long-distance observation.
-
115 mm → Maximum light gathering capacity, professional-grade performance.
-
-
SWAROVISION Optical TechnologyExtremely high resolution and edge sharpness, true color reproduction.
-
All-weather protectionNitrogen-filled, waterproof, and anti-fog structure.
-
Strong and durableMetal structure with rubber protective layer, earthquake resistant and weather resistant.
📏 Product Specifications
| Specifications | 65 mm module | 85 mm module | 95 mm module | 115 mm module |
|---|---|---|---|---|
| caliber | 65 mm | 85 mm | 95 mm | 115 mm |
| length | Approximately 207 mm | Approximately 240 mm | Approximately 294 mm | Approximately 307 mm |
| weight | Approximately 775 g | Approximately 1,100 g | Approximately 1,340 g | Approximately 2,100 g |
| Magnification (with ATX/STX) | 25–60× | 25–60× | 30–70× | 30–70× |
| Minimum focusing distance | Approximately 2.1 m | Approximately 3.6 m | Approximately 4.8 m | Approximately 4.8 m |
| Field of view (@1000 m) | 41–23 m | 41–23 m | 35–19 m | 35–19 m |
| Protective structure | Waterproof, anti-fog, nitrogen-filled | ditto | ditto | ditto |
| colour | green | green | green | green |
| Origin | Made in Austria | Made in Austria | Made in Austria | Made in Austria |
📦 Package Contents
-
Objective lens module × 1 (depending on aperture)
-
Lens protection cap × 1 set
-
Carrying bag × 1
-
Original instruction manual and warranty card × 1
🛒 Reasons to buy
✅ Compatible with ATX / STX / BTX main modules
✅ Four caliber options to meet different usage needs
✅ SWAROVISION High-Resolution Optical Technology
✅ Waterproof and anti-fog design, suitable for all weather conditions.
✅ Made in Austria, reliable quality
| caliber |
65mm, 85mm, 95mm, 115mm |
|---|
